Audio DSP Processor 12 Channel Echo Cancellation PeopleLink Pro Audio DSP

Audio DSP Processor 12 Channel Echo Cancellation PeopleLink Pro Audio DSP About

12 channel audio DSP processor: 8 mic inputs, 4 line inputs, 6 outputs, full-bandwidth echo cancellation and smart mixing. PeopleLink Pro Audio DSP.

PeopleLink Pro Audio DSP key specifications

• 8 balanced mic inputs and 4 balanced line inputs, Phoenix connectors, 48 V phantom power
• 6 balanced line outputs
• Full-bandwidth adaptive echo cancellation; adaptive noise reduction up to 18 dB
• Smart mixing, matrix mixing, 10-band parametric EQ, limiter, compressor, feedback suppression, delay
• 48 kHz sampling, 24-bit conversion; dynamic range over 105 dB
• Ethernet for setup from PC software; RS-232 for third-party control

What does an audio DSP do in a conference room?

A DSP such as the PeopleLink Pro Audio DSP takes every microphone in the room, removes echo and noise, mixes them automatically and sends clean audio to the far end and to the room speakers.

Can it be controlled from a room control system?

Yes. The PeopleLink Pro Audio DSP has an RS-232 port for third-party control and Ethernet for configuration.

Why PeopleLink?

PeopleLink builds the DSP, the microphones, the speakers and the room controller as one signal chain with one support owner.

Get a quote: send your room size, number of microphones, and your city.
